Pinarello Dyodo eRoad Bike

$7,999.00

Free 2-Day shipping on orders over $50. Learn More

Select a Size:

Find your size
|

Note: Actual inseam is not the same as pant inseam.How to measure

Recommended Size

We recommend a size in this bike.

EditMore details

Our size calculator is a starting point for finding the right size for you. To get personal advice talk to one of our fit experts at 1.888.276.7130 or chat now

Select options
  • Select options
    • 50
    • 53
    • 55
    • 58

    Select a Color:

    Select options
  • Select options
    • 960 Carbon/Red

    Be the first to review

    Details

    Dyodo eRoad Bike

    Many of us are familiar with Pinarello as the brand of bikes that Team Sky powers to some of the most prestigious road race victories on the calendar. We marvel at how quickly the pros are able to ride their bikes and appear nearly tireless during the longest stage races and often wonder what that sensation would feel like. PED jokes aside, what if we told you the Dyodo eRoad Bike from Pinarello allowed you to do just that and whether you're just getting into road cycling and you'd like to keep up with your buddies, wonder how much more you'd commute with electric assist, or maybe you have a health condition and want to ride just as fast and as far as you used to? Well, electric assist can help. Of course, it doesn't hurt that the Pinarello Dyodo has the same design and clean lines as its World Tour winning Dogma and you'd have to look real hard to even notice that it's an eRoad bike.

    The good news is the Dyodo also rides like a Pinarello should thanks to its material choice, tapered steerer, and geometry. What you get is a bike that's stiff under power, corners like it's on rails, and its super light as well, with power assist on demand. Pinarello builds almost all of its frames exclusively out of carbon fiber, so getting the frame construction were it needed to be wasn't a hard task for the brand, however, the Dyodo differs from the brand's first eRoad offering, the Nytro, by moving the motor to the rear hub, in this instance, the Ebikemotion X35 pedal assist system, and the battery is hidden away from sight in the frame's downtube. The motor and battery only add 7.7lbs to the build making it one of the lightest pedal assist systems on the market as well as one of the cleanest looking setups.

    The hub-based motor adds 250-watts and is powered by a battery that's fully recharged in 4 hours. This allows Pinarello to get the center of gravity low and allow it to build the frame, especially its downtube and bottom bracket junction, retaining a house-favorite Italian threading, much like its traditional, non-eRoad frames, where it enjoys class-leading stiffness and weight numbers. It uses T700 unidirectional carbon, just like on the brand's Prince, as its proven itself to be very lightweight but also very resilient. Another returning frame construction feature is its asymmetrical design building in extra strength and responsiveness as the bike sees different forces on the drive and non-drive sides.

    Pinarello also recognized that cheating the wind is just as important in saving yours or your batteries' reserves and employed aerodynamic features we've seen before on its Bolide and Dogma F10 frames to the Dyodo, think Flat Back tube profiles and fork flaps, helping to smooth the passing wind and reduce turbulence. A quick peek at the geometry chart reveals that the numbers are more akin to a race bike than and endurance cruiser and that translates to stable handling at speed with just enough agility on twisty descents.

    The pedal assist motor will help up to speeds of 20mph, after that, you're on your own. Battery life depends on many factors including elevation, rider weight, wind etc., however, a good approximation is around 4,000ft of elevation gain in maximum support mode. Pinarello is working on an additional water bottle mounted battery that can double the range. Furthermore, the Ebikemotion hub is set up with a PAS Sensor that uses 20 magnets to detect how much power to add or disengage to your effort so you don't incur undue friction while coasting. Unit controls happen via an iWoc button that's easy to reach on the frame's top tube. You can choose the level of support from zero to maximum with a press of the button and the system pairs with an app where you can customize settings for each push that's easy to access from your phone or a smartwatch.

    Other bike features include a full SRAM Force build kit complete with hydraulic disc brakes. Cockpit duties are handled by Pinarello's house brand Most and the rolling stock consists of Mavic Aksium Tubeless Disc wheels. Altogether, it’s a bike that will literally give you a boost on group rides and allow you to ride with speed even if you don't have the time to train like a pro.

    • A pedal-assist bike for group rides or commutes
    • The hub-based motor is lighter and offers a cleaner setup
    • Race geometry is similar to its GT-winning Dogma
    • T700 carbon fiber from the experts at Toray is light and durable
    • Italian threaded bottom bracket is creak-free and easy to service
    • Tire clearance up to 28mm for better grip and comfort
    • SRAM Force group offers plenty of gearing and powerful brakes
    • Pinarello's palmares speak for themselves
    • Item #PIN006B

    Tech Specs

    Frame Material
    T700 Carbon
    Fork
    Dyodo disc
    Headset
    Pinarello 1-1/8 - 1.5in tapered
    Shifters
    SRAM Force HRD
    Front Derailleur
    SRAM Force 22
    Rear Derailleur
    SRAM Force 22
    Drive System
    ebikemotion X35
    Motor Power
    [nominal] 250w
    Battery Type
    lithium-ion
    Max Speed
    20mph
    Crankset
    SRAM Force 22
    Chainring Sizes
    34 / 50t
    Crank Arm Length
    [46.5, 50cm] 170mm, [53, 55cm] 172.5mm, [58cm] 175mm
    Bottom Bracket
    SRAM Force
    Bottom Bracket Type
    Italian
    Cassette
    SRAM Force 22
    Cassette Range
    11 - 32t
    Chain
    SRAM Force 22
    Brakeset
    SRAM Force Hydro
    Brake Type
    Flat-mount hydraulic disc
    Rotors
    SRAM Centerline 160mm
    Handlebar
    MOst Jaguar XA Aero
    Handlebar Width
    o-t-o [46.5, 50cm] 42cm, [53, 55cm] 44cm, [58cm] 46cm
    Stem
    MOst Tiger Alu Aero
    Stem Length
    [46.5cm] 90mm, [50, 53cm] 100mm, [55cm] 110mm, [58cm] 120mm
    Saddle
    MOst X3
    Seatpost
    Aero Full Carbon UD
    Wheelset
    Mavic Aksuim Disc
    Front Axle
    12mm Thru-Axle
    Rear Axle
    12 x 142mm
    Tires
    Pirelli Cinturato Velo
    Tire Size
    700c x 28mm
    Pedals
    not included
    Claimed Weight
    12000g
    Recommended Use
    road cycling
    Manufacturer Warranty
    2 years on frame
