Tech Specs:

Frame Material, Main Triangle:

Aluminum

Frame Material, Rear Triangle/Swing Arm:

Aluminum

Seat stay Material:

Aluminum

Chain stay Material:

Aluminum

Suspension Linkage Material:

N/A

Pivot Type:

Cartridge Bearing

Rear Travel:

4in (100mm)

Frame Travel Adjustments:

N/A.

Suspension:

Single Pivot

Frame Geometery Adjustments:

N/A

Shock Included:

Fox Float R

Headset:

1.125in Syncros

Integrated Chain Guide:

N\A

Accessory Cable Stop:

N/A

Rear Axle:

135 x 10mm

Fork:

Fox F100R 100mm travel

Wheelset:

Shimano XT/Mavic 117 Disc

Front Derailleur:

Shimano SLX

Rear Derailleur:

Shimano XT Shadow RD-M772

Shifters:

Shimano SLX SL-M660

Crankset:

Shimano SLX

Teeth:

22 / 32 / 44T

Crank Arm Length:

[M] 175mm

Bottom Bracket:

Shimano

Brake Levers:

Avid Juicy Five

Brakes:

Juicy Five

Rotors:

160mm/160mm

Headset:

Syncros

Head Angle:

71 Deg.

Handlebar:

Race Face Evo

Handlebar Width:

670

Handlebar Rise:

Low Riser

Grips:

Lizard Skin

Stem:

Race Face Evolve XC

Stem Length:

100mm

Stem Angle:

6 Deg.

Chain:

Shimano CN-HG73

Chain Guide:

N/A

Cassette:

Shimano CS-HG80-9

Range:

11-34

Tire Front:

Kenda Nevagal

Tire Front Size:

26 x 2.1in

Tire Rear:

Kenda Nevagel

Tire Rear Size:

26 x 2in

Tubes:

Presta

Seatpost:

Race Face Evolve XC

Seatpost Diameter:

27.2mm

Seatpost Length:

300mm

Cables / Housing:

Shimano

Saddle:

WTB Rocket V

Seat Collar:

non-QR

Weight:

[m]27lbs.01oz

Recommended Use:

XC, XC race

Manufacturer Warranty:

2 Years
